0.6/1kv聚氯乙烯绝缘交联聚乙烯绝耐火电缆

upload of：2016-03-31 09-33-50 updated：admin

0.6/1kw聚氯乙烯绝缘、交联聚乙烯绝缘耐火电缆
一、产品性能：
耐火电缆参照gb/t12706-2002标准。耐火特性符合gb/t18380-2001标准
本产品采用耐火云母带作为耐火层，护套采用阻燃聚氯乙烯护套料。
二、使用特性：
本产品适用于交流额定电压0.6/1kv及以下配电线路、需要具有耐火特性的场合。
电缆敷设时环境温度不低于0℃，最小弯曲半径为电缆外径的15倍。

电缆的型号规格：

型号	名称	芯数	导电线芯标称截面mm²
nh-vv	铜芯聚氯乙烯绝缘聚氯乙烯护套耐火电缆	1-5	1.5-240
nh-vv₂₂	铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装耐火电缆	1-5	2.5-240
nh-yjv	铜芯交联聚乙烯绝缘聚氯乙烯护套耐火电缆	1-5	1.5-240
nh-yjv₂₂	铜芯交联聚乙烯绝缘钢带铠装聚氯乙烯护套耐火电缆	1-5	2.5-240

电缆规格芯数×截面mm²	电缆外径mm		电缆计算重量kg/km		20℃导体直流电阻ω/km	电缆参考载流量（a）
电缆规格芯数×截面mm²	非铠装	铠装	非铠装	铠装	20℃导体直流电阻ω/km	在空气中	在土壤中
1×1.5	8.7		87		12.1	24	29
1×2.5	9.1		102		7.41	31	38
1×4	10.0		131		4.61	41	49
1×6	10.5		156		3.08	52	61
1×10	11.8	17.0	211	468	1.83	72	83
1×16	12.9	18.1	278	558	1.15	95	105
1×25	14.5	19.7	387	695	0.727	120	135
1×35	15.6	20.8	494	823	0.524	150	160
1×50	17.1	22.5	657	1012	0.387	180	195
1×70	18.5	23.7	851	1235	0.268	230	240
4×95	20.7	25.9	1119	1540	0.193	280	285
1×120	22.4	27.0	1367	1818	0.153	325	250
1×150	24.4	29.7	1680	2173	0.124	375	290
1×185	26.5	32.1	2041	2587	0.991	430	335
1×240	29.5		2604		0.0754	510	395
2×1.5	15.5		228		12.1	15	22
2×2.5	16.3	19.7	270	478	7.41	19	29
2×4	18.2	21.6	361	591	4.61	26	38
2×6	19.3	22.7	434	678	3.08	32	47
2×10	22.1	25.4	613	891	1.83	46	65
2×16	24.3	27.7	823	1130	1.15	60	84
2×25	27.8	33.1	1166	1861	0.727	77	110
2×35	30.5	35.7	1515	2271	0.524	95	130
2×50	34.0	39.2	2041	2878	0.387	115	155
2×70	37.3	42.7	2697	3622	0.268	145	195

电缆规格芯数×截面mm²	电缆外径mm		电缆计算重量kg/km		20℃导体直流电阻ω/km	电缆参考载流量（a）
电缆规格芯数×截面mm²	非铠装	铠装	非铠装	铠装	20℃导体直流电阻ω/km	在空气中	在土壤中
2×95	42.4	48.1	3569	4656	0.193	185	230
2×120	46.1	51.8	4385	5551	0.153	210	260
2×150	50.7	56.7	5417	6731	0.124	245	300
2×185	55.9	62.0	6652	8107	0.0991	280	335
2×240	62.3	68.7	8478	10124	0.0754	335	390
4×4	19.4	22.8	411	657	4.61	26	38
4×6	20.8	24.2	514	776	3.08	32	47
4×10	23.5	26.8	704	997	1.83	46	65
4×16	26.1	29.7	963	2303	1.15	60	84
4×25	29.8	35.0	1366	2106	0.727	77	110
4×35	32.2	37.4	1706	2500	0.524	95	130
4×50	36.1	41.5	2342	3237	0.387	115	155
4×70	39.5	45.0	3068	4065	0.268	145	195
4×95	45.0	50.6	4114	5250	0.195	185	230
4×120	49.0	54.8	5115	6375	0.153	210	260
4×150	52.9	59.0	6163	7508	0.124	245	300
4×185	58.8	65.0	7603	9159	0.0991	280	335
4×240	65.2	71.7	9640	11405	0.0754	335	390
5×2.5	19.2	22.6	394	641	7.41	19	29
5×4	21.6	25.0	528	800	4.61	26	38
5×6	23.0	26.3	645	934	3.08	32	47
5×10	26.4	31.7	921	1582	1.83	46	65
5×16	29.3	34.6	1282	2009	1.15	60	84
5×25	34.0	39.2	1841	2686	0.727	77	110
5×35	37.5	43.0	2425	3325	0.524	95	130
5×50	41.8	47.3	3306	4332	0.387	115	155
5×70	45.8	51.5	4333	5193	0.268	145	195
5×95	52.2	58.1	5772	7125	0.193	185	230
5×120	57.2	63.3	7125	8616	0.153	210	260
