聚氯乙烯绝缘控制电缆

upload of：2016-03-31 09-35-49 updated：admin

一、产品性能：

1、产品依据gb9330-88国家标准。
2、电缆能经受交流50hz、3000v，施压时间5分钟的耐高压试验。
3、绝缘线芯浸水1小时后，经受耐高压试验不击穿。

二、使用特性：
1、本产品适用于交流额定电压450/750v（uo/u）或直流1000v及以下控制，监控回路及保护线路等场合。
2、电缆长期最高工作温度70℃。
3、电缆工作电压应不大于额定电压的1.1倍。

型号规格：

型号	名称					主要使用范围
kvv	铜芯聚氯乙烯绝缘聚乙烯护套控制电缆					敷设在室内、电缆沟、管道固定场合
kvvp	铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制电缆					敷设在室内、电缆沟、管道等要求屏蔽的固定场合
kvv₂₂	铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装控制电缆					敷设在室内、电缆沟、管道、直埋等能承受较大机械外力等固定场合
kvvr	铜芯聚氯乙烯绝缘聚氯乙烯护套控制软电缆					敷设在室内移动要求柔软等场合
kvvrp	铜芯聚氯乙烯绝缘聚氯乙烯护套编辑屏蔽控制电缆					敷设在室内移动要求柔软、屏蔽等场合
型号	额定电压	导体标称截面mm²
		0.5	0.75	1.0	1.5	2.5	4	6	10
		芯数
kvv kvvp	450/750		2-37				2-14		2-10
kvv22			7-37			4-37	4-14		4-10
kvvr		4-37
kvvrp		4-37			4-37

450/750v控制电缆结构尺寸、技术性能：

芯数	导体截面	kvv（kvvr）				kvv₂₂						kvv（kvvrp）					性能
	导体截面	绝缘厚度	护套厚度	电缆重量	电缆计算外径	绝缘厚度	内设厚度	钢带层×厚	外设厚度	电缆重量	电缆计算外径	绝缘厚度	铜丝厚度	护套厚度	电缆重量	电缆计算外径	导体最大电阻	试验电压
	mm²	mm	mm	kg/km	mm	mm	mm	mm	mm	kg/km	mm	mm	mm	mm	kg/km	mm	20℃ω/km	kv
2	0.75	0.6	1.2	60.1	7.07							0.6	0.15	1.2	80.6	8.1	24.5	3
	1.0	0.6	1.2	71.3	7.39							0.6	0.15	1.2	99.7	8.4	18.1	3
	1.5	0.7	1.2	89.7	8.31							0.7	0.15	1.2	112.7	9.4	12.1	3
	2.5	0.8	1.2	125.4	9.53							0.8	0.15	1.2	156.4	10.8	7.41	3
	4	0.8	1.2	156.8	10.5							0.8	0.20	1.5	228.7	12.7	4.61	3
	6	0.8	1.2	205.7	11.5							0.8	0.20	1.5	299.6	13.8	3.08	3
	10	1.0	1.5	349.0	15.5							1.0	0.20	1.5	408.5	16.5	1.83	3
3	0.75	0.6	1.2	69.3	7.41							0.6	0.15	1.2	94.8	8.4	24.5	3
	1.0	0.6	1.2	81.2	7.76							0.6	0.15	1.2	107.6	8.8	18.1	3
	1.5	0.7	1.2	112.5	8.75							0.7	0.15	1.2	140.2	9.8	12.1	3
	2.5	0.8	1.2	162.6	10.1							0.8	0.15	1.2	195.6	11.3	7.41	3
	4	0.8	1.2	212.0	11.1							0.8	0.20	1.5	297.2	13.3	4.61	3
	6	0.8	1.5	300.4	12.8							0.8	0.20	1.5	330.5	14.6	3.08	3
	10	1.0	1.5	479.7	16.5							1.0	0.20	1.5	540.0	17.5	1.83	3
4	0.75	0.6	1.2	88.5	7.99							0.6	0.15	1.2	115.3	9.0	24.5	3
	1.0	0.6	1.2	107.2	8.38							0.6	0.15	1.2	130.6	9.5	18.1	3
	1.5	0.7	1.2	139.6	9.49							0.7	0.15	1.2	168.7	10.6	12.1	3
	2.5	0.8	1.2	196.5	11.0	0.8	1.2	2×0.2	1.5	424.5	15.2	0.8	0.20	1.2	270.9	13.2	7.41	3
	4	0.8	1.5	285.6	12.7	0.8	1.2	2×0.2	1.5	516.4	16.3	0.8	0.20	1.5	347.2	14.4	4.61	3
	6	0.8	1.5	375.7	14.0	0.8	1.2	2×0.2	1.7	627.9	17.6	0.8	0.20	1.5	474.2	15.8	3.08	3
	10	1.0	1.5	630.4	18.1	1.0	1.2	2×0.2	1.7	937.6	22.1	1.0	0.20	1.5	700.3	19.4	1.83	3
5	0.75	0.6	1.2	100.9	8.63							0.6	0.15	1.7	135.1	9.7	24.5	3
	1.0	0.6	1.2	119.7	9.06							0.6	0.15	1.2	156.0	10.3	18.1	3
	1.5	0.7	1.2	169.1	10.3							0.7	0.15	1.2	199.8	11.5	12.1	3
	2.5	0.8	1.5	258.4	12.6	0.8	1.2	2×0.2	1.5	487.2	16.2	0.8	0.20	1.2	313.3	14.2	7.41	3
	4	0.8	1.5	339.9	13.9	0.8	1.2	2×0.2	1.5	589.7	17.5	0.8	0.20	1.5	412.6	15.6	4.61	3
	6	0.8	1.5	451.4	15.2	0.8	1.2	2×0.2	1.7	743.1	19.3	0.8	0.20	1.5	570.5	17.2	3.08	3
	10	1.0	1.7	787.0	20.3	1.0	1.2	2×0.2	1.7	1143	23.9	1.0	0.20	1.5	844.7	21.2	1.83	3
7	0.75	0.6	1.2	125.2	9.30							0.6	0.15	1.7	160.0	10.4	24.5	3
	1.0	0.6	1.2	150.8	9.78	0.6	1.2	2×0.2	1.5	375.3	14.0	0.6	0.15	1.2	185.3	10.9	18.1	3
	1.5	0.7	1.2	204.5	11.2	0.7	1.2	2×0.2	1.5	436.2	15.4	0.7	0.15	1.5	263.3	13.2	12.1	3
	2.5	0.8	1.5	317.7	13.6	0.8	1.2	2×0.2	1.5	564.1	17.2	0.8	0.20	1.5	391.2	15.3	7.41	3
	4	0.8	1.5	429.3	15.0	0.8	1.2	2×0.2	1.5	699.0	18.6	0.8	0.20	1.5	515.8	16.9	4.61	3
	6	0.8	1.5	579.9	16.6	0.8	1.2	2×0.2	1.7	895.3	20.6	0.8	0.20	1.5	725.9	18.6	3.08	3
	10	1.0	1.7	993.7	22.1	1.0	1.2	2×0.2	1.7	1381	25.7	1.0	0.20	1.7	1073	23.0	1.83	3
8	0.75	0.6	1.2	143.1	9.97							0.6	0.15	1.2	179.9	11.1	24.55	3
	1.0	0.6	1.2	172.7	10.5	0.6	1.2	2×0.2	1.5	392.4	14.7	0.6	0.15	1.5	195.6	12.4	18.1	3
	1.5	0.7	1.5	253.5	12.7	0.7	1.2	2×0.2	1.5	483.4	16.2	0.7	0.15	1.5	308.1	14.2	12.1	3
	2.5	0.8	1.5	364.0	14.7	0.8	1.2	2×0.2	1.5	628.0	18.3	0.8	0.20	1.5	441.0	16.4	7.41	3
	4	0.8	1.5	493.2	16.2	0.8	1.2	2×0.2	1.7	801.8	20.2	0.8	0.20	1.7	595.0	18.5	4.61	3
	6	0.8	1.7	687.1	18.3	0.8	1.2	2×0.2	1.7	1009	21.9	0.8	0.20	1.7	835.6	20.1	3.08	3
	10	1.0	1.7	1144	24.0	1.0	1.2	2×0.2	1.7	1562	27.6	1.0	0.20	1.7	1258	25.2	1.83	3

10	0.75	0.6	1.2	175.7	11.5							0.6	0.20	1.5	252.3	13.6	24.5	3
	1.0	0.6	1.5	232.3	12.8	0.6	1.2	2×0.2	1.5	464.9	16.4	0.6	0.20	1.5	287.3	14.3	18.1	3
	1.5	0.7	1.5	310.8	14.6	0.7	1.2	2×0.2	1.5	574.5	18.7	0.7	0.20	1.5	378.4	16.3	12.1	3
	2.5	0.8	1.5	449.4	17.1	0.8	1.2	2×0.2	1.7	774.3	21.1	0.8	0.20	1.5	543.0	19.0	7.41	3
	4	0.8	1.7	634.6	19.4	0.8	1.2	2×0.2	1.7	974.2	23.0	0.8	0.20	1.7	738.9	21.5	4.61	3
	6	0.8	1.7	856.6	21.4	0.8	1.2	2×0.2	1.7	1231	25.0	0.8	0.25	1.7	1068	24.0	3.08	3
	10	1.0	1.7	1448	28.3	1.0	1.2	2×0.2	2.0	1986	32.5	1.0	0.25	1.7	1572	29.4	1.83	3
12	0.75	0.6	1.5	219.3	12.5							0.6	0.20	1.5	280.0	14.0	24.5	3
	1.0	0.6	1.5	263.2	13.2	0.6	1.2	2×0.2	1.5	502.1	16.8	0.6	0.20	1.5	323.9	14.7	18.1	3
	1.5	0.7	1.5	259.4	15.1	0.7	1.2	2×0.2	1.5	630.4	19.1	0.7	0.20	1.5	424.8	16.7	12.1	3
	2.5	0.8	1.5	521.3	17.6	0.8	1.2	2×0.2	1.7	855.8	21.6	0.8	0.20	1.7	634.9	20.0	7.41	3
	4	0.8	1.7	735.2	20.0	0.8	1.2	2×0.2	1.7	1085	23.6	0.8	0.20	1.7	845.8	22.1	4.61	3
	6	0.8	1.7	991.6	22.1	0.8	1.2	2×0.2	1.7	1378	25.7	0.8	0.25	1.7	1214	24.8	3.08	3
14	0.75	0.6	1.5	246.6	13.1							0.6	0.20	1.5	307.5	14.6	24.5	3
	1.0	0.6	1.5	298.6	13.8	0.6	1.2	2×0.2	1.5	548.0	17.4	0.6	0.20	1.5	358.3	15.4	18.1	3
	1.5	0.7	1.5	405.6	15.8	0.7	1.2	2×0.2	1.7	708.2	19.8	0.7	0.20	1.5	472.5	17.5	12.1	3
	2.5	0.8	1.5	598.6	18.9	0.8	1.2	2×0.2	1.7	949.2	22.5	0.8	0.20	1.7	714.3	20.9	7.41	3
	4	0.8	1.7	839.9	21.0	0.8	1.2	2×0.2	1.7	1207	24.6	0.8	0.20	1.7	959.0	23.2	4.61	3
	6	0.8	1.7	1135	23.3	0.8	1.2	2×0.2	1.7	1540	26.9	0.8	0.25	1.7	1404	26.0	3.08	3
16	0.75	0.6	1.5	277.1	13.7							0.6	0.20	1.5	399.6	15.3	24.5	3
	1.0	0.6	1.5	322.7	14.5	0.6	1.2	2×0.2	1.5	593.7	18.1	0.6	0.20	1.5	397.1	16.1	18.1	3
	1.5	0.7	1.5	456.4	16.4	0.7	1.2	2×0.2	1.5	773.5	21.7	0.7	0.20	1.5	526.0	18.4	12.1	3
	2.5	0.8	1.7	695.3	19.9	0.8	1.2	2×0.2	1.7	1045	23.5	0.8	0.25	1.7	791.7	22.0	7.41	3
19	0.75	0.6	1.5	305.5	14.4							0.6	0.20	1.5	382.2	16.0	24.5	3
	1.0	0.6	1.5	372.9	15.2	0.6	1.2	2×0.2	1.7	664.2	19.2	0.6	0.20	1.5	448.8	16.9	18.1	3
	1.5	0.7	1.5	513.5	17.5	0.7	1.2	2×0.2	1.7	845.9	21.7	0.7	0.20	1.7	613.6	19.3	12.1	3
	2.5	0.8	1.7	782.6	21.0	0.8	1.2	2×0.2	1.7	1150	23.5	0.8	0.25	1.7	905.0	23.1	7.41	3
24	0.75	0.6	1.5	384.5	16.6							0.6	0.20	1.5	467.9	18.3	24.5	3
	1.0	0.6	1.5	471.1	17.6	0.6	1.2	2×0.2	1.7	805.1	19.2	0.6	0.20	1.7	570.8	19.8	17.1	3
	1.5	0.7	1.5	665.5	20.8	0.7	1.2	2×0.2	1.7	1029	21.5	0.7	0.20	1.7	759.3	22.6	12.1	3
	2.5	0.8	1.7	984.5	24.2	0.8	1.2	2×0.2	1.7	1410	24.6	0.8	0.25	1.7	1133	27.1	7.41	3
27	0.75	0.6	1.5	417.5	16.9							0.6	0.20	1.5	505.9	18.6	24.5	3
	1.0	0.6	1.5	512.1	17.9	0.6	1.2	2×0.2	1.7	852.7	21.6	0.6	0.20	1.7	615.2	20.1	18.1	3
	1.5	0.7	1.5	730.3	21.2	0.7	1.2	2×0.2	1.7	1102	24.4	0.7	0.20	1.7	824.0	23.1	12.1	3
	2.5	0.8	1.7	1058	24.9	0.8	1.2	2×0.2	1.7	1520	28.5	0.8	0.25	1.7	1236	27.6	7.41	3
30	0.75	0.6	1.5	458.6	17.5							0.6	0.20	1.7	563.8	19.6	24.5	3
	1.0	0.6	1.5	582.2	19.0	0.6	1.2	2×0.2	1.7	916.2	22.6	0.6	0.20	1.7	667.7	20.8	18.1	3
	1.5	0.7	1.5	803.5	22.0	0.7	1.2	2×0.2	.17	1187	25.6	0.7	0.20	1.7	928.1	24.2	12.1	3
	2.5	0.8	1.7	1195	25.9	0.8	1.2	2×0.2	1.7	1645	29.5	0.8	0.25	1.7	1350	28.6	7.41	3
37	0.75	0.6	1.5	557.9	19.3							0.6	0.20	1.7	662.9	21.0	24.5	3
	1.0	0.6	1.5	686.9	20.4	0.6	1.2	2×0.2	1.7	1045	24.0	0.6	0.20	1.7	788.3	22.3	18.1	3
	1.5	0.7	1.5	954.9	23.6	0.7	1.2	2×0.2	1.7	1367	27.2	0.7	0.20	1.7	1097	25.9	12.1	3
	2.5	0.8	1.7	1433	27.9	0.8	1.2	2×0.2	2.0	1963	32.1	0.8	0.25	2.0	1654	31.4	7.41	3
